Inherent safety DCS isolation station

In response to the serious security deficiencies in the production control network, OptimiPro Control Teach. has developed an "intrinsic security DCS isolation station" that uses a unique "photographic data transmission technology" to achieve completely one-way data transmission from DCS to real-time databases. No matter how viruses and hackers change, the mechanism of data transmission eliminates the possibility of attacks on DCS through external networks.

Our company has developed "network security isolation" or "network physical isolation" products through "photographic data transmission technology", including "intrinsic security DCS isolation station", "network isolation system based on photographic data transmission technology", and additional products such as redundant systems.

This technology has currently obtained a national invention patent (ZL200610064971.8), as well as international patents such as US 8341741 B2, Canada (No. 2645722), Russia (No. 2426248), South Korea (No. 10-1146184), and Japan (No. 4971420).

Product features:

1、Exclusive national invention patent for photographic data transmission technology.

2、Under non network connection conditions, DCS data can be transmitted completely unidirectionally to the real-time database (0-bit return), achieving true network physical disconnection and completely avoiding the intrusion of external network viruses and hackers, essentially ensuring the security of DCS.

3、Automatically run upon startup.

4、Support tag type self checking, adaptive, and output.

5、The "Shadow Server" with built-in OPC Server complies with the OPC2.0 international standard, and its data values and status are the same as those in DCS OPC Server.

6、Supports multiple input/output interfaces, such as OPC, API, MODBUS, etc.

7、Capable of debugging and simulation testing environment.

8、Support backup for both off line and online stations.

9、The OPC Client has the function of intelligent detection and automatic reconnection after disconnection to OPC server.

10、Provide a configuration tool for editing tag list.

11、Has high reliability and stable performance.

12、Numerical processing complies with IEEE international standards.

13、The basic version has a maximum data transfer capacity of 6000Tag/s, while the advanced version can transfer up to 12000Tag/s.

14、Support online addition and deletion of tags.

15、Supports timed transfer of specific files .

16、Built in database sampling client, supporting automatic data caching in case of network disconnection.

17、One isolation station can isolate multiple sets of DCS (multiple input models).

18、Equipped with a fault self check alarm function (equipped with a fault monitoring platform server).

19、Used in conjunction with real-time monitoring alarm and automatic redundancy switching system to achieve centralized remote fault detection alarm, automatic/manual redundancy scheme switching (such as backup station switching, BYPASS switching) management.
